Programatoare automate de ardere TMG740-3 32.32

Technical Data:

Supply voltage 220 / 240 V (-15... +10%)
50 HZ (40 - 60 Hz)
AC frequency variations result in proportional timing deviations
Fuse rating 10 A rapid, 6 A slow
Power consumption approx. 15 VA
Max. current per
output terminal 4 A
Total 6 A
Sensitivity
Ionisation input 1.6 mA
UV input 70 mA
Min. sensor current
Ionisation/IR probe 5 mA = 2 LED
UV tube 250 mA = 2 LED
Air proving switch 6 A, 220 V
Reset delay none
Flame detector cable
Ionisation 50 m normal cable
100 m screened cable
UV tube 100 m normal cable
200 m screened cable
UV tube UVZ 780 blue low sensitivity
UVZ 780 white medium sensitivity
UVZ 780 red high sensitivity
Weight incl. base 1100 g
Mounting attitude any
Insulation standard IP 44
Permissable ambient temp. -20 A° C to +60 A° C incl.
